型号 | 转鼓直径MM | 处理量L/H | 运行功率KW | 进出口MM | 底座面积M2 | 高度MM | 质量KG |
CE50-N | 50 | 2~100 | 0.08-0.1 | 15 | 340 x 280 | 760 | 35 |
CE150-N | 150 | 100-1000 | 0.5-1.0 | 32 | 500 x 500 | 1150 | 300 |
CE250-N | 250 | 1000-3000 | 1.5-2.0 | 50 | 725 x 725 | 1730 | 800 |
CE350-N | 350 | 3000-10000 | 2.0-4.0 | 80 | 910 x 910 | 2120 | 1000 |
CE450-N | 450 | 8000-15000 | 4.5-7.0 | 80 | 1100 x 1100 | 2250 | 1400 |
CE550-N | 550 | 12000-30000 | 7.0-10.0 | 100 | 1300 x 1300 | 2750 | 2000 |
CE650-N | 650 | 25000-40000 | 11.0-15.0 | 125 | 1600 x 1600 | 3200 | 2500 |
CE800-N | 800 | 40000-70000 | 15.0-20.0 | 150 | 1800 x 1800 | 3500 | 3500 |
CE1000-N | 1000 | 60000-100000 | 22.0-28.0 | 150 | 2000 x 2000 | 3800 | 5000 |
